Bison Compression Ltd. Decant Panels for industrial gas/ virtual pipelines are the key to optimising the amount of gas being delivered and protecting the equipment downstream of the panel. Poor component selection and control can reduce the amount of gas and cause issues with regulators and valves.
Bison Decanting Panel Systems offer a number of unique features specifically designed to optimise delivery and protect equipment downstream of the decant panel. This can increase delivery of gas in some cases up to 30% and decrease the required maintenance on the pressure reducing system significantly.
Standard Features:
- Steel framing system
- ¾ to 1 1/2” main pipe lines
- Inbuilt bleed system vented to 3M above the ground
- High post coupling system
- Stainless steel valve housing enclosure
- Inlet and outlet control Valves
- Single or dual hose
Optional features:
- High Flow rate coupling system
- Fully automated trailer change over
- Single or dual trailer post
- Flow Meter
- Low Surge operating valve system
- Manual and Automated changeover system
- Internal gas regulators for control valves
- Simple coupling holder solutions
Bison Compression Ltd offer the most comprehensive solutions for your CNG trailer decanting requirements.
Please contact the team at Bison Compression for specifications and other information.
